Bailey · motorhome
Bailey Approach Autograph 745
RoamWorthy records the Bailey Approach Autograph 745 as a motorhome. Recorded catalogue data: 4 berths; layout: French bed; length 7.45m; width 2.42m; height 2.79m; MTPLM 3,500kg; payload 371kg; recorded model year: 2016; recorded price range £42,000 to £58,000. No live dealer stock is currently linked to this model on RoamWorthy. Specifications can vary by model year, trim and optional equipment. Check the individual listing and manufacturer documentation before purchase.
Bailey Approach Autograph 745 key facts
- Berths: 4
- Unladen weight: 3129 kg
- Payload: 371 kg
- Length: 7.45 m
- Width: 2.42 m
- Observed price range: £42,000 to £58,000
Key features
- Alu-Tech bodyshell construction system
- Alde hydronic central heating and water heating system
- Ultra-low profile AL-KO AMC chassis for enhanced stability
- Fixed rear 'French' bed with memory foam mattress
- Fully integrated kitchen with Thetford Caprice oven and microwave
- Four travel seats with 3-point inertia reel seatbelts
- Exterior gas BBQ point and 230v socket
Bailey Approach Autograph 745: Layout and Berth Facts
The Bailey Approach Autograph 745 is a motorhome with 4 berths. Recorded layout tags include French Bed and Front Lounge.
- Four berth capacity with four dedicated travel seats featuring three-point inertia reel seatbelts.
- Fixed rear French bed layout complemented by a front lounge that converts into additional sleeping space.
- Built on an ultra-low profile AL-KO AMC chassis powered by a Peugeot Boxer 2.2 BlueHDi engine.
- Year-round capability via Grade III thermal insulation and an Alde hydronic central heating system.
- Kitchen equipped with a Thetford Caprice oven, microwave, and integrated appliances.
Worth knowing: The 7.45m length may require careful navigation in standard parking bays. The French bed design requires the occupant on the inside to climb over their partner to exit. Payload capacity is impacted when travelling with four adults.
Buying a Bailey Approach Autograph 745
Who it suits
- Couples seeking a dedicated rear bedroom with the convenience of a fixed bed.
- Small families requiring four travel seats and a convertible social hub.
- Winter tourers who benefit from the Grade III insulation and silent Alde heating.
Reasons to consider it
- The AL-KO AMC chassis provides a lower centre of gravity for enhanced driving stability.
- The Alu-Tech construction system offers superior protection against the elements.
- A generous 371kg payload is provided for a vehicle in this class.
What to check
- Inspect the condition of the Mendip Ash furniture and high-quality upholstery for wear.
- Test the Alde hydronic heating system and water heater for consistent operation.
- Check the exterior gas BBQ point and 230v socket for signs of corrosion or damage.
- Ensure the memory foam mattress on the fixed French bed remains supportive.
Worth knowing: Confirm the specific engine output as Peugeot Boxer specifications can vary by year. Verify the remaining payload after accounting for any fitted optional equipment.
Compare the Bailey Approach Autograph 745 with similar models
| Model | Berths | Maximum weight | Length | Typical price |
|---|---|---|---|---|
| Bailey Approach Autograph 745 | 4 | 3500 kg | 7.45 m | £42,000 to £58,000 |
| Elddis Evolution | 4 | 3500 kg | 7.34 m | £45,000 to £78,000 |
| Elnagh Baron 530 | 4 | 3500 kg | 7.41 m | £42,000 to £68,000 |
The Bailey Approach Autograph 745 sits in a competitive segment alongside models like the Auto-Trail Imala 736 and Elddis Evolution. While the Bailey focuses on the specific benefits of the AL-KO chassis and Alde heating, its 7.45m length is slightly greater than several rivals. All these models share a 3500kg MTPLM, but the Bailey distinguishes itself with its specific French bed and corner washroom configuration. Choosing between them often depends on a preference for the Alu-Tech construction versus the different interior lengths and layouts offered by the Elddis or Elnagh alternatives.
Worth knowing: Specifications and prices can vary by model year, trim and optional equipment.
Ownership and Maintenance Tips
- Utilise the exterior 230v socket and BBQ point to extend the living space outdoors.
- Regularly inspect the Alu-Tech bodyshell seals to maintain the thermal integrity.
- Make use of the low step-in height for easier access during frequent stops.
Common mistakes to avoid
- Overloading the 371kg payload when four adults are travelling together.
- Neglecting to check the specific licence requirements for a vehicle of this length.
Worth knowing: The 2.42m width requires extra attention on narrow rural roads. The 2.79m height must be considered when approaching low bridges or height barriers.
Alternatives to the Bailey Approach Autograph 745
- Elddis Evolution - A similarly sized model worth comparing on layout, weight and price.
- Elnagh Baron 530 - The Elnagh Baron 530 provides an alternative four berth layout within the same 3500kg weight category and a similar starting price.
- Auto-Trail Imala 736 - A similarly sized model worth comparing on layout, weight and price.
Data and source notes
- This page uses the maintained RoamWorthy record for the Bailey Approach Autograph 745.
- 6 model images are recorded for this page and served from RoamWorthy-hosted media.
- 2 recorded source groups are available in the source section below.
Proof notes
- Specifications can differ by production year, trim and optional equipment.
- Dealer listings are used as current marketplace evidence, not as a substitute for the exact vehicle documentation.
Worth knowing: Confirm weights, dimensions and fitted equipment for the exact vehicle before purchase or towing.
Sources and review status for the Bailey Approach Autograph 745
This page is supported by 2 recorded source groups.
- Bailey of Bristol media (manufacturer_media)
- RoamWorthy maintained model catalogue (editorial_database)
Last reviewed: 2026-07-30T10:28:57.573379+00:00
