Bailey · motorhome
Bailey Approach Autograph 765
RoamWorthy records the Bailey Approach Autograph 765 as a motorhome. Recorded catalogue data: 6 berths; layout: Rear Lounge; length 7.45m; width 2.49m; height 2.83m; MTPLM 3,850kg; payload 570kg; base vehicle: Peugeot Boxer; recorded model year: 2016; recorded price range £45,000 to £82,000. No live dealer stock is currently linked to this model on RoamWorthy. Specifications can vary by model year, trim and optional equipment. Check the individual listing and manufacturer documentation before purchase.
Bailey Approach Autograph 765 key facts
- Berths: 6
- GVW: 3850 kg
- Unladen weight: 3280 kg
- Payload: 570 kg
- Length: 7.45 m
- Width: 2.49 m
- Base vehicle: Peugeot Boxer
- Observed price range: £45,000 to £82,000
Key features
- High-performance Peugeot Boxer 2.2 BlueHDi engine
- Alde hydronic central heating and water heating system
- Spacious U-shaped rear lounge with panoramic views
- Electric drop-down double bed over the front dinette
- Fully equipped kitchen with 153L large capacity fridge-freezer
- AL-KO AMC chassis for improved road holding and lower center of gravity
- Safety-tested rear travel seats for up to 6 passengers
A versatile six-berth family motorhome with dual living zones.
The Bailey Approach Autograph 765 is a 7.45m long motorhome designed for large families, offering six berths and six travel seats. It is distinguished by its dual-lounge configuration, featuring a U-shaped rear lounge and a front dinette with an electric drop-down bed. Built on a Peugeot Boxer chassis with an AL-KO AMC frame, it utilizes the Alde hydronic heating system for four-season use. With an MTPLM of 3850kg, it provides a 570kg payload but requires a C1 driving licence.
- Six-berth capacity with six safety-tested travel seats.
- Dual-lounge layout featuring a U-shaped rear lounge and front dinette.
- Electric drop-down double bed positioned over the front seating area.
- Alde hydronic central heating system for year-round climate control.
- Peugeot Boxer 2.2 BlueHDi engine on an AL-KO AMC low-profile chassis.
Worth knowing: The 3850kg MTPLM requires a C1 category driving licence. A 7.45m external length may prove difficult to park in standard bays. Payload is limited to 570kg, which may be tight when fully loaded with six adults.
Buying a Bailey Approach Autograph 765
Who it suits
- Large families requiring six dedicated travel seats and sleeping berths.
- Tourists seeking separate living zones for children and adults.
- Winter travellers who benefit from the Alde hydronic heating system.
Reasons to consider it
- The U-shaped rear lounge provides panoramic views and a spacious social area.
- The AL-KO AMC chassis offers a lower centre of gravity for improved road holding.
- It features a fully equipped kitchen with a dual-fuel hob and large fridge.
What to check
- Test the electric drop-down bed mechanism for smooth operation.
- Inspect the Alde heating system service history to ensure four-season efficiency.
- Check the condition of the 153L fridge-freezer and kitchen appliances.
- Verify the C1 licence status of all intended drivers due to the 3850kg weight.
Worth knowing: Confirm the specific engine output as specifications can vary by model year. Verify the remaining payload after accounting for any fitted optional equipment.
Compare the Bailey Approach Autograph 765 with similar models
| Model | Berths | Maximum weight | Length | Typical price |
|---|---|---|---|---|
| Bailey Approach Autograph 765 | 6 | 3850 kg | 7.45 m | £45,000 to £82,000 |
| Bailey Autograph | 6 | 3850 kg | 7.41 m | £45,000 to £95,000 |
| Bailey Autograph 79 6 | 6 | 3850 kg | 7.98 m | £45,000 to £75,000 |
The Bailey Approach Autograph 765 occupies a specific niche for families needing six travel seats and six berths within a 7.45m footprint. While the 3850kg MTPLM necessitates a C1 licence, it allows for the inclusion of the heavy Alde heating system and a 570kg payload. In comparison, alternatives like the Benimar Tessoro or Auto-Trail Tribute T 736 offer six berths on a 3500kg chassis, which avoids licence restrictions but may result in different equipment levels or payload capacities. The 765 remains a robust choice for those prioritising the dual-lounge layout and premium heating.
Worth knowing: Specifications and prices can vary by model year, trim and optional equipment.
Ownership and Maintenance Tips
- Utilise the 570kg payload carefully when travelling with a full capacity of six adults.
- Regularly check the seals on the large panoramic windows and skylights.
- Ensure the Peugeot Boxer chassis is serviced according to manufacturer intervals.
Common mistakes to avoid
- Attempting to drive the vehicle on a standard B category licence.
- Overlooking the 2.49m width when navigating narrow rural lanes.
Worth knowing: Payload calculations must include the weight of all six passengers and water.
Alternatives to the Bailey Approach Autograph 765
- Bailey Autograph - A similarly sized model worth comparing on layout, weight and price.
- Bailey Autograph 79 6 - The Autograph 79 6 offers a similar six-berth capacity but with a longer body length of 7.98m for those requiring more interior volume.
- Benimar Tessoro - The Benimar Tessoro provides six berths within a 3500kg MTPLM, making it accessible to drivers without a C1 licence category.
Data and source notes
- This page uses the maintained RoamWorthy record for the Bailey Approach Autograph 765.
- 10 model images are recorded for this page and served from RoamWorthy-hosted media.
- 4 recorded source groups are available in the source section below.
Proof notes
- Specifications can differ by production year, trim and optional equipment.
- Dealer listings are used as current marketplace evidence, not as a substitute for the exact vehicle documentation.
Worth knowing: Confirm weights, dimensions and fitted equipment for the exact vehicle before purchase or towing.
